This new Crypto-Coin Miner allows you to mine different algos with a very competitive price per kw/h. The advantage of these powerfull FPGA chips (Xilinx) is their extremely low power consumption. Our AtomMiners draw about 16 watts max and reach a hashrate comparable to an up to date mid-range GPU graphic card from NVIDA GeForce or AMD Radeon series.
Due to this advantage in power consumption it’s not only cheaper to mine but it’s also possible to run the AtomMiner FPGA with a solar panel and archive a completely sustainable, green blockchain. Some managed to run the miner by solar panel at daytime and use a car battery at night which would be recharged with solar energy.
Provided you have a mobile internet connection (eg. through your smartphone) you could even mine cryptos while driving supplying it with 12V car connector.
- Xilinx 7 Series FPGA inside (from official Xilinx distributors)
- Automatic FPGA reconfiguration
- Almost instant FPGA configuration with soft start to lower energy consumption
- True Scalability with no interruption
- Hot-Swap and Plug-and-Play support
- Hashrate comparable to GPU at only 1/10 or less power consumption
- True USB2.0/USB3.0 communication interface
- Minimum requirement for the host computer
- Universal 12VDC power input
- Low Power consumption
- Small & Lightweight
- Silent operation
- 3 Years warranty
- State-of-the-art Software designed exclusively for AtomMiner
- Every host PC can control up to 64 miners simultaneously
- We support Raspberry Pi 1/2/3 right out of the box
- Miners can be connected and disconnected without interrupting mining
- Seamless integration with AtomMiner Pool and other services
- Detailed and realtime mining statistics
- Pre-configured downloadable OS images
- Free lifetime software and firmware updates
- No dev fees
- Portable
- No heat
- Constant updates
| Power connection | DC 5.5/2.1mm | |
| Power supply voltage | 12VDC | |
| Input current (Idle) | 150mA | |
| Input current (Hashing), max | 1.3A |
| Data Connection | USB Type B | |
| Size | 110x67x45mm | |
| Operating Temperature (Environment) | 0 – 40℃ | |
| Storage Temperature | -25 – 100℃ | |
| Weight | 200g |
Currently Supported Algorithms and Coins
| Algo | Coin(s) | Version | Hashrate | Power | Release date |
|---|---|---|---|---|---|
| Keccak/Keccak-C | MaxCoin, CREA, SLOTH, BCT, GLT | 1.3 | 540 MH/s | 18W | May 2019 |
| SHA-3 | Zen Protocol | 1.2 | 500 MH/s | 17.5W | Postponed |
| SHA256 | BTC and many others | 1.1 | 500 MH/s | 16W | April 2019 |
| Blakecoin | BLC, UMO, PHO, BBTC, ELT, LIT | 1.2 | 1200 MH/s | 13W | February 2019 |
| Gr0estl | GRS | 1.1 | 32 MH/s | 10W | June 2019 |
| Skein2 | LOG | 1.0 | 44 MH/s | 6.7W | June 2019 |
| Myriad | GLT, AUR, ARG, DGB, XMY, XSH, XVG and more | 1.0 | 32 MH/s | 9.8W | July 2019 |
| SHA-256t | OCP | 1.0 | 180 MH/s | 10W | July 2019 |
| SHA-256q | PYE | 1.0 | 150 MH/s | 11W | July 2019 |
| Odocrypt | DGB | 1.0 | 50 MH/s | 7.2W | July 2019 |
| Tribus | D, BZL, GLT | 1.0 | 25 MH/s | 9W | Dec 2019 |
| Blockstamp | BST | 1.0 | 300 MH/s | 11W | Dec 2019 |
| Blake2s | GLT | 1.0 | 1200 MH/s | 12W | Dec 2019 |
For future updates and developments please visit the current roadmap.
Estimated camparison for Hashrate and MH/Watt:
Algo: Keccak/Keccak-C/SHA-3
| Device | Hashrate | Power | MHash per Watt |
|---|---|---|---|
| Nvidia GTX 750 Ti | 140MH/s | 60W | 2.33 |
| Nvidia GTX 1070 | 480MH/s | 150W | 3.42 |
| Nvidia GTX 1080 Ti | 1050MH/s | 280W | 3.75 |
| AMD R9 380 | 180MH/s | 215W | 0.84 |
| AMD RX 470 | 215MH/s | 140W | 1.54 |
| AMD RX 580 | 310MH/s | 225W | 1.38 |
| AtomMiner AM01 | 540MH/s | 18W | 30 |
Algo: Blakecoin
| Device | Hashrate | Power | MHash per Watt |
|---|---|---|---|
| Nvidia GTX 750 Ti | 800MH/s | 74W | 15.99 |
| Nvidia GTX 1070 | 4930MH/s | 180W | 27.5 |
| Nvidia GTX 1080 Ti | 8030MH/s | 280W | 28.78 |
| AMD R9 380 | 2100MH/s | 205W | 10.25 |
| AMD RX 470 | 2339MH/s | 135W | 17.33 |
| AMD RX 580 | 3620MH/s | 175W | 20.69 |
| AtomMiner AM01 | 1200MH/s | 13W | 92.31 |
Some GPUs might receive a higher hashrate, they most likely draw more energy too.
*Warranty of our Atomminers is 12 month.
